Dimension Drawing
Unit : mm
| Part Number | D | M (Coarse) Nominal of Thread |
Pitch | Lf | H | Mass (g) |
CAD Download |
Cart |
|---|---|---|---|---|---|---|---|---|
| KGB-32-M10 | 32 | M10 | 1.5 | 16 | 29 | 25 | CAD | RFQ |
Material/Finish
| KGB | |
|---|---|
| Ball Part | EPDM (Matte Black) |
| Thread Part | S45C Trivalent Chromate Treatment |
Characteristics
- Made of gum with soft touch.
