Non-Magnetic
These screws have low magnetic permeability.
They are suitable for semiconductor manufacturing equipment, FPD manufacturing equipment, electronic devices, and MRI machines where magnetic interference is undesirable.
In addition to bolts, nuts, and washers, non-magnetic tools are also available.
These are ideal for assembling and maintaining equipment and devices in strong magnetic field environments.
| Image |  |
 |
 |
 |
 |
 |
 |
 |
 |
|---|---|---|---|---|---|---|---|---|---|
| Part Name | Socket Head Cap Captive Screws - Titanium | Phosphor Bronze Pan Head Machine Screws for Precision Instruments (Miniature Screws) | Cross Recessed Pan Head Machine Screws - High Intensity Titanium Alloy | Cross Recessed Pan Head Machine Screws - Titanium | Phillips Pan Head Captive Screws - Brass | Brass Cross Recessed Micro Pan Head Machine Screws - Type 0-1 | Brass Cross Recessed Micro Pan Head Machine Screws with Nylon Patch - Type 0-1 | Cross Recessed Flat Head Machine Screws - High Intensity Titanium Alloy | Cross Recessed Flat Head Machine Screws - Titanium |
| Part Number | SSC-SNST | SNZP | SNPTG | SNPT | SSCPB | SNZB | SNZB-ALK | SNFTG | SNFT |
| Feature | Lightweight Non-magnetic Chemical Resistance Captive / Loss Prevention |
Non-magnetic Pan Head Machine Screws for Precision Instruments |
High Strength Lightweight Nonmagnetic Corrosion Resistance |
Lightweight Nonmagnetic Chemical Resistance |
Pan Head Machine Screws Captive / Loss Prevention |
Non-magnetic Pan Head Machine Screws for Precision Instruments |
Non-magnetic Pan Head Machine Screws for Precision Instruments Nylon Patch |
High Strength Lightweight Nonmagnetic Corrosion Resistance |
Lightweight Nonmagnetic Chemical Resistance |
| Material | Grade 2 Titanium | C5191 (Phosphor Bronze) | β Titanium | Grade 2 Titanium | Brass | Brass | Brass | β Titanium | Grade 2 Titanium |
| Surface Treatment | Special Chemical Polishing | - | Special Chemical Polishing | Special Chemical Polishing | - | - | - | Special Chemical Polishing | Special Chemical Polishing |
| Thread Size | M3 ～ M6 | M2 ～ M2.5 | M3 ～ M5 | M2 ～ M5 | M3 ～ M8 | M2 ～ M2.6 | M2 ～ M2.6 | M3 ～ M5 | M3 ～ M4 |
| Operating Temperature (℃) | - | - | - | - | - | - | - | - | - |
| CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD |
| Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications |
| List | SSC-SNST-M3 SSC-SNST-M4 SSC-SNST-M5 SSC-SNST-M6 | SNZP-M2 SNZP-M2.5 | SNPTG-M3 SNPTG-M4 SNPTG-M5 | SNPT-M2 SNPT-M2.5 SNPT-M3 SNPT-M4 SNPT-M5 | SSCPB-M3 SSCPB-M4 SSCPB-M5 SSCPB-M6 SSCPB-M8 | SNZB-M2 SNZB-M2.6 | SNZB-M2.6-ALK SNZB-M2-ALK | SNFTG-M3 SNFTG-M4 SNFTG-M5 | SNFT-M3 SNFT-M4 |
| Image |  |
 |
 |
 |
 |
 |
 |
 |
|
|---|---|---|---|---|---|---|---|---|---|
| Part Name | Hex Nuts / Hex Flange Nuts - Titanium | Hex Nuts / Hex Flange Nuts - Titanium | Hex Lock Nuts - Titanium | Washers - Titanium | Washers - Titanium | Hex Socket Head Cap Screws - Phosphor Bronze | CFRTP Adjustable Wrench | Titanium Hexagon Key | |
| Part Number | SHNT | SHNT-F | SWUT | SWAT-F | SWAT-S | SNSP | SKMWCP-200 | SKHTG | |
| Feature | Lightweight Nonmagnetic Chemical Resistance |
Lightweight Nonmagnetic Chemical Resistance With Flange |
Lightweight Nonmagnetic Vibration Resistant |
Lightweight Nonmagnetic Chemical Resistance |
Lightweight Nonmagnetic Chemical Resistance |
Non-Magnetic | Non-magnetic Tool | Non-magnetic Tool | |
| Material | Grade 2 Titanium | Grade 2 Titanium | Grade 2 Titanium | Grade 2 Titanium | Grade 2 Titanium | C5191 (Phosphor Bronze) | CFRTP (Carbon Fiber Reinforced Thermoplastics resin) | Grade 5 Titanium | |
| Surface Treatment | Special Chemical Polishing | Special Chemical Polishing | Special Chemical Polishing | - | - | - | - | Barrel Polishing | |
| Thread Size | M3 ～ M10 | M3 ～ M10 | M3 ～ M10 | M3 ～ M10 | M3 ～ M10 | M2 ～ M8 | - | - | |
| Operating Temperature (℃) | - | - | - | - | - | - | - | - | |
| CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD | |
| Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | |
| List | SHNT-M10 SHNT-M3 SHNT-M4 SHNT-M5 SHNT-M6 SHNT-M8 | SHNT-M10-F SHNT-M3-F SHNT-M4-F SHNT-M5-F SHNT-M6-F SHNT-M8-F | SWUT-M10 SWUT-M3 SWUT-M4 SWUT-M5 SWUT-M6 SWUT-M8 | SWAT-10-F SWAT-3-F SWAT-4-F SWAT-5-F SWAT-6-F SWAT-8-F | SWAT-10-S SWAT-3-S SWAT-4-S SWAT-5-S SWAT-6-S SWAT-8-S | SNSP-M2 SNSP-M2.5 SNSP-M3 SNSP-M4 SNSP-M5 SNSP-M6 SNSP-M8 | SKMWCP-200 | SKHTG-1.5 SKHTG-2 SKHTG-2.5 SKHTG-3 SKHTG-4 SKHTG-5 SKHTG-6 |
