Dimension Drawing
Specs/CAD
Unit : mm
| Part Number | M (Coarse) Nominal of Thread |
Pitch | D1 | H | A | Qty per Pack | Mass (g) |
CAD Download |
RFQ |
|---|---|---|---|---|---|---|---|---|---|
| SPO-M4-YN | M4 | 0.7 | 20 | 10 | 8 | 10 | 0.39 | CAD | RFQ |
| SPO-M5-YN | M5 | 0.8 | 25 | 12 | 10 | 10 | 0.68 | CAD | RFQ |
| SPO-M6-YN | M6 | 1 | 32 | 16 | 12 | 10 | 1.4 | CAD | RFQ |
| SPO-M8-YN | M8 | 1.25 | 40 | 20 | 16 | 10 | 2.9 | CAD | RFQ |
Nabeya Bi-tech Kaisha
Customer Service
Please enter questions about customization and other product-related inquiries here.
Find the inquiry form here
● When purchasing less volume than one full bag, a separate handling fee is charged. For details, see the Sold Separately Service.
Related Services
Material/Finish
| SPO-YN | |
|---|---|
| Main Body | POM (Polyacetal) |
| Heat Resistance Temperature＊1 | 95℃ |
＊1： This is the value for the resin material. The operating temperature of the product changes with performance conditions such as tightening torque.
Application
General industrial machines / Food industry machines / Medical equipment / Audio equipmentCharacteristics
- It has excellent chemical resistance compared to metal screws.
- It can be installed/removed without the use of tools.
- The properties and precautions of plastic screws⇒Plastic Screws
