Stages
About Stages
Manual stages are machine elements in which the stage feed is manual, enabling fixing and position adjustment at any location.
They are mainly used in optical and precision machinery fields, where precise positioning is called for.
NBK offers linear, rotary, and gonio types.
| Image |  |
 |
 |
 |
 |
 |
 |
 |
 |
|---|---|---|---|---|---|---|---|---|---|
| Part Name | Miniature X-axis Rack-and-Pinion Stages | Miniature X / Y-axis Rack-and-Pinion Stages | Miniature Z-axis Rack-and-Pinion Stages | X-axis Rack-and-Pinion Stages | Miniature X-axis Rack-and-Pinion Stages | Precision X-axis Rack-and-Pinion Stages | Precision Rotary Stages | Precision Rotary Stages | X-axis Screw Stages |
| Part Number | TAR-X | TAR-XY | TAR-Z | TAR | TAR-25 | TAR-D | TKSP | TAKS | TAS |
| Feature | X-axis | X-axis Y-axis |
Z-axis | X-axis | X-axis | X-axis | Rotation | Rotation | X-axis |
| stage | 25×50 | 25×50 | 25×50 | 34×60 | 25×30 | 38×60 | φ60 | φ98 | 24×30 |
| move | ±10 | ±10 | ±10 | ±15 | ±25 | - | - | - | ±4 |
| CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD | CAD |
| Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications | Specifications |
| List | TAR-2550X | TAR-2550XY | TAR-2550Z | TAR-60 TAR-80 | TAR-25121 TAR-25161 TAR-2581 | TAR-60D TAR-80D | TKSP-60 | TAKS-100 | TAS-30 TAS-60 |
